Name: 618-C 636-C Bowey Replaces PECO Activated Carbon Canister
Brand: BoweyFilter
SKU: 618-C 636-C
Availability: InStock
Rating: 5 (1 reviews)

618-C 636-C Bowey Replaces PECO Activated Carbon Canister

Description FAQ Review

Description

618-C 636-C Bowey Replaces PECO Activated Carbon Canister

Bowey High Quality Activated Carbon Filter Canister

Bowey activated carbon filter canisters adopt 100% virgin coal-based granular activated carbon with deep high-temperature steam activation. Featuring abundant adsorption sites and powerful adsorption capacity, they are designed with radial outside-in flow structure. Equipped with electroplated steel support and double-layer cotton protective mesh, the canisterss have solid construction and smooth flow paths. With excellent temperature and pressure resistance and extended service life, they are compatible with PECO Series 10 and similar filter housings. They effectively improve fluid quality and reduce operation & maintenance costs, serving as a reliable solution for industrial fluid deep purification.

Feature

• Made of 100% virgin coal-based granular activated carbon via high-temperature steam activation for sufficient adsorption sites.

• Outperforms shell-based carbon and blended regenerated carbon with longer service life.

• Outside-in filtration design ensures thorough adsorption and stable differential pressure.

• Direct replacement for PECO Series 10 and equivalent filter housings, easy to install.

• High temperature and pressure resistance, suitable for amine solution, ethylene glycol, lubricating oil and various other fluids.

Materials
Carbon	Granular Activated Carbon
Core	Perforated plated steel
Core cover	Cotton
Outer cover	Cotton
Outer core	Perforated plated steel
End caps	Plated steel
Handle	Stainless steel
Operating Parameters
Max temp.	300ºF / 149ºC
Max differential pressure	90 psid / 6.2 bar
Flow direction	Radial, outside to inside
Recommended flow rate	1.3gpm/4.92lpm per canister

How to Check if Carbon canisters Needs Replacing?

1. Visual Inspection: Compare samples of inlet and outlet liquid. If the outlet liquid shows no obvious decolorization, the carbon is saturated.

2. Shake Test: If foam from shaken outlet liquid persists and does not dissipate quickly, the canisters needs replacement.

3. Scheduled Maintenance: For working conditions with stable contaminant load, replace the canisters at regular intervals.

Installation & Usage Recommendations

1. A particulate pre-filter is mandatory. It prevents solid contaminants from clogging the carbon bed and extends adsorption service life.

2. A post security filter is recommended to trap escaped carbon fines and protect downstream equipment.

Part Number	O.D.	I.D.	Length
618-C	6.25” / 158.7mm	2.625” / 66.675mm	18.25” / 463.55mm
636-C	6” / 152.4mm	3.50” / 88.9mm	36” / 914.4mm
719-C	7.25” / 184.2mm	2.25” / 57.2mm	19.25” / 488.95mm
720-C	7.25” / 184.2mm	1.56” / 39.6mm	20.5” / 520.7mm
720-C-2.25	7.25” / 184.2mm	2.25” / 57.2mm	20.5” / 520.7mm
722-C	7.4” / 188mm	1.56” / 39.6mm	22.25” / 565.2mm
1120-C	11” / 279.4mm	2.25” / 57.2mm	20.25” / 514.4mm
1122-C	11” / 279.4mm	1.56” / 39.6mm	22.25” / 565.2mm
1122-C-2.25	11” / 279.4mm	2.25” / 57.2mm	22” / 558.8mm
1122-C-2.25 N	11” / 279.4mm	2.25” / 57.2mm	22.25” / 565.2mm
